FEATURE
- Compliance: SAE J595, CA T13
- Ingress Protection Rating: IP67
- Housing: Aluminum
- Accessories: L bracket, screws*4, switch panel*1 or control box*1
- Mounting Options: Permanent
- Available in: 3 / 4 / 6 / 8 High power LED versions
SPECIFICATION
- Model Name: SL3X / SL4X series
- Input Voltage: 10~30V
- Input Current:
– 3 or 6 LED 2 module 1.0/2.0A max @DC12V
– 3 or 6 LED 4 module 1.6/3.2A max @DC12V
– 3 or 6 LED 6 module 2.4/4.8A max @DC12V
– 3 or 6 LED 8 module 3.2/6.4A max @DC12V
– 4 LED 2 module 1.6A max @DC12V
– 4 or 6 LED 4 module 3.2A max @DC12V
– 4 LED 6 module 4.8A max @DC12V
– 4 LED 8 module 6.4A max @DC12V - Ambient Temperature Range: -30 ~ 50°C
- Flash Patterns: 25 (2 modules), 31 (4/6/8 modules)
